11 5-8" 537 TCI tricone rock bits in stock
Cangzhou Great PDC Bits Co., ltd. specializes in designing, manufacturing, marketing and serving the high performance diamond bits and drilling tools used in petroleum industry. The company is established by the top experts of the field, and equipped with advanced equipments and facilities.
IADC Code Classifications
STEEL TOOTH BITS
IADC 1 SERIES DRILL BITS
These bits are used to drill low-compressive strength, soft formations. Long projection tooth lengths are used on high offset cones to provide the greatest penetration rates possible. Wear-resistant hardfacing is used to control tooth wear. On the softest bit types this hardfacing completely covers the bit teeth.
IADC 2 SERIES DRILL BITS
These bits are used to drill high-compressive strength, medium hard formations. Short projection teeth with reduced crest length are used in this series of bit designs. Durable hardfacing is applied to reduce tooth wear.
IADC 3 SERIES DRILL BITS
These bits are used to drill hard and abrasive formations. Very short, closely spaced teeth with minimum amounts of hardfacing are used for breakage resistance. These bits must withstand high loads and drill abrasive formations with a crushing, cutting action.
TCI BITS
tricone rock bit:
1. journal bearing, hardfaced hear bearing surface
2. Oring seal is made of the more wear resistance high staturated buna-N with the increased seal section and precisely designed sealing flange in the cone sealing area increased the reliablity of the seal
3. the bit bearing can be ball locked or ring locked
4. new type of grease that can sustain high temperature up to 250 degrees centigrade.
5. size avaliable from 3 7/8"(98.4mm) to 26"(660.4mm).
IADC 4 SERIES DRILL BITS
These bits are used to drill low compressive strength, very soft formations. The bits maximize the use of both conical and chisel inserts of large diameters and high projection. This cutting structure design, combined with maximum cone offset, results in high bit penetration rates. The deep intermesh of cutter rows prevents bit balling in sticky formations.
IADC 5 SERIES DRILL BITS
These bits are used to drill low compressive strength, soft to medium soft formations. Drill bit design features are used to enhance bit penetration rates. Some reduction in cone offset and insert projection is used to improve cutter durability. Insert numbers and pitch is controlled to prevent tracking.
IADC 6 SERIES DRILL BITS
These bits are used to drill high-compressive strength, medium hard formations. A small amount of cone offset and low insert projection is used to prevent cutting structure damage when hard streaks are encountered. Increased numbers of blunter, smaller diameter inserts are used to increase life in harder, more abrasive formations.
IADC 7 SERIES DRILL BITS
These bits are used to drill hard and abrasive formations. A more wear-resistant grade of tungsten carbide insert is used to prevent wear. Low cone offset with increased numbers of breakage resistant cutters add to the required bit durability.
IADC 8 SERIES DRILL BITS
These bits can be used to drill extremely hard and abrasive formations. Wear-resistant inserts are used in the outer rows to prevent loss of bit gauge. Maximum numbers of hemispherical-shaped inserts are used in all rows to provide cutter durability and long life.
11 5-8" 537 TCI tricone rock bits in stock
